February 02, 2020 8 min read

OVERVIEW


A diagnostic trouble code (DTC) is made up of 5 characters- 1 letter followed by 4 digits. The letter of an OBDII code identifies the location of the fault code (i.e. P- Powertrain). The first digit indicates where it is a generic code or a manufacturer specific code. The second digit indicates the subsystem (i.e. 7= transmission). The last two digits are the fault description.


With this information you can easily determine what system to troubleshoot without knowing the exact code description, however we took it a step further and have provided you with a master DTC code reference list below. Additionally, we have provided you with a master list of transfer case control module (TCCM) codes as well.

What is a DTC?



6.7L POWERSTROKE MASTER DTC CHART



DTC
Description



P0125
Insufficient Coolant Temp For Closed Loop Fuel Control

P0128
Coolant Thermostat (Coolant Temp Below Thermostat Regulating Temperature)

P0217
Engine Coolant Overtemperature Condition

P0218
Transmission Fluid Temperature Sensor "A" Over Temperature Condition

P0462
Fuel Level Sensor A Circuit Low

P0463
Fuel Level Sensor A Circuit High

P0504
Brake Switch A / B Correlation

P0532
A/C Refrigerant Pressure Sensor “A” Circuit Low

P0533
A/C Refrigerant Pressure Sensor “A” Circuit High

P0562
System Voltage Low

P0563
System Voltage High

P0572
Brake Switch A Circuit Low

P0573
Brake Switch A Circuit High

P0620
Generator Control Circuit

P0625
Generator Field Terminal Circuit Low

P0626
Generator Field Terminal Circuit High

P0645
A/C Clutch Relay Control Circuit

P0646
A/C Clutch Relay Control Circuit Low

P0647
A/C Clutch Relay Control Circuit High

P0657
Actuator Supply Voltage "A" Circuit/Open

P065B
Generator Control Circuit Range/Performance

P06E4
Control Module Wake-up Circuit Performance

P06E9
No engine rotation detected during crank event

P0701
Transmission Control System Range/Performance

P0702
Transmission Control System Electrical

P0706
Transmission Range Sensor "A" Circuit Range/Performance

P0707
Transmission Range Sensor "A" Circuit Low

P0708
Transmission Range Sensor "A" Circuit High

P0710
Transmission Fluid Temperature Sensor "A" Circuit

P0711
Transmission Fluid Temperature Sensor "A" Circuit Range/Performance

P0712
Transmission Fluid Temperature Sensor "A" Circuit Low

P0713
Transmission Fluid Temperature Sensor "A" Circuit High

P0715
Turbine/Input Shaft Speed Sensor "A" Circuit

P0717
Turbine/Input Shaft Speed Sensor "A" Circuit No Signal

P0718
Turbine/Input Shaft Speed Sensor "A" Circuit Intermittent

P0720
Output Shaft Speed Sensor Circuit

P0721
Output Shaft Speed Sensor Circuit Range/Performance

P0722
Output Shaft Speed Sensor Circuit No Signal

P0729
Gear 6 Incorrect Ratio

P0731
Gear 1 Incorrect Ratio

P0732
Gear 2 Incorrect Ratio

P0733
Gear 3 Incorrect Ratio

P0734
Gear 4 Incorrect Ratio

P0735
Gear 5 Incorrect Ratio

P0740
Torque Converter Clutch Solenoid Circuit/Open

P0741
Torque Converter Clutch Solenoid Circuit Performance/Stuck Off

P0742
Torque Converter Clutch Solenoid Circuit Stuck On

P0743
Torque Converter Clutch Solenoid Circuit Electrical

P0744
Torque Converter Clutch Solenoid Circuit Intermittent

P0748
Pressure Control Solenoid "A" Electrical

P0750
Shift Solenoid "A"

P0751
Shift Solenoid "A" Performance/Stuck Off

P0752
Shift Solenoid "A" Stuck On

P0753
Shift Solenoid "A" Electrical

P0754
Shift Solenoid "A" Intermittent

P0755
Shift Solenoid "B"

P0756
Shift Solenoid "B" Performance/Stuck Off

P0757
Shift Solenoid "B" Stuck On

P0758
Shift Solenoid "B" Electrical

P0759
Shift Solenoid "B" Intermittent

P0760
Shift Solenoid "C"

P0761
Shift Solenoid "C" Performance/Stuck Off

P0762
Shift Solenoid "C" Stuck On

P0763
Shift Solenoid "C" Electrical

P0764
Shift Solenoid "C" Intermittent

P0765
Shift Solenoid "D"

P0766
Shift Solenoid "D" Performance/Stuck Off

P0767
Shift Solenoid "D" Stuck On

P0768
Shift Solenoid "D" Electrical

P0769
Shift Solenoid "D" Intermittent

P0770
Shift Solenoid "E"

P0771
Shift Solenoid "E" Performance/Stuck Off

P0772
Shift Solenoid "E" Stuck On

P0773
Shift Solenoid "E" Electrical

P0774
Shift Solenoid "E" Intermittent

P0850
Park / Neutral Switch Input Circuit

P0882
TCM Power Input Signal Low

P0883
TCM Power Input Signal High

P0960
Line Pressure Control (LPC) A Control Circuit/Open

P0961
Pressure Control Solenoid "A" Control Circuit/Open

P0962
Pressure Control Solenoid "A" Control Circuit Low

P0963
Pressure Control Solenoid "A" Control Circuit High

P0973
Shift Solenoid "A" Control Circuit Low

P0974
Shift Solenoid "A" Control Circuit High

P0976
Shift Solenoid "B" Control Circuit Low

P0977
Shift Solenoid "B" Control Circuit High

P0979
Shift Solenoid "C" Control Circuit Low

P0980
Shift Solenoid "C" Control Circuit High

P0982
Shift Solenoid "D" Control Circuit Low

P0983
Shift Solenoid "D" Control Circuit High

P1001
KOEO Not Able to Complete, KOER Aborted

P1299
Cylinder Head Overtemperature Protection Active

P1397
System Voltage Out Of Self Test Range

P145B
A/C Demand Not Activated During Self Test

P1464
A/C Demand Out Of Self Test Range

P1501
Vehicle Speed Sensor Out Of Self Test Range

P1548
Engine Air Filter Restriction

P1594
Forced engine shutdown – remote start system fault, No unattended vehicle timeout

P1595
Forced engine shutdown – remote start system fault, transmission range not in park

P161A
Incorrect Response from Immobilizer Control Module

P162F
Starter Motor Disabled - Engine Crank Time Too Long

P1636
Inductive Signature Chip Communication Error

P1637
CAN Link ECM/ABS Control Module Circuit/Network

P163A
Generator "B" Control Circuit

P163C
Generator "B" Field Terminal Circuit Low

P163D
Generator "B" Field Terminal Circuit High

P163E
Transmission Control Module Programming Error

P163F
Transmission ID Block Corrupted, Not Programmed

P1678
Low Oil Pressure Lamp Control Circuit

P1702
Transmission Range Sensor Circuit Intermittent

P1703
Brake Switch Out Of Self-Test Range

P1705
Transmission Range Circuit Not Indicating Park/Neutral During Self Test

P1709
Park Neutral Position Switch Out Of Self Test Range

P1711
Transmission Fluid Temperature Sensor Out Of Self Test Range

P1744
Torque Converter Clutch Solenoid Circuit

P177F
Unable to Fully Engage Neutral

P1783
Transmission Over Temperature Condition

P1921
Transmission Range Signal

P1933
Fuel Level Signal

P193C
Steering Wheel Angle Signal

P193E
A/C Clutch Request Signal

P2535
Ignition Switch Run/Start Position Circuit High

P25B0
Fuel Level Sensor "A" Stuck

P2700
Transmission Friction Element "A" Apply Time Range/Performance

P2701
Transmission Friction Element "B" Apply Time Range/Performance

P2702
Transmission Friction Element "C" Apply Time Range/Performance

P2703
Transmission Friction Element "D" Apply Time Range/Performance

P2704
Transmission Friction Element "E" Apply Time Range/Performance

P2705
Transmission Friction Element "F" Apply Time Range/Performance

P2758
Torque Converter Clutch Pressure Control Solenoid Stuck On

P2760
Torque Converter Clutch Pressure Control Solenoid Intermittent

U0102
Lost Communication with Transfer Case Control Module

U0121
Lost Communication With Anti-Lock Brake System (ABS) Control Module

U0151
Lost Communication With Restraints Control Module

U0212
Lost Communication With Steering Column Control Module

U0402
Invalid Data Received from TCM



Transmission Control Module (TCM) DTC List

P0657
Actuator Supply Voltage A Circuit Open

P0701
Transmission Control System Range/Performance
Transmission hydraulic and clutch systems (including non-electrical shift solenoid faults, main control valve body and clutch(es)).

P0702
Transmission Control System Electrical
Battery

P0705
Transmission Range Sensor "A" Circuit (PRNDL Input)
TR sensor

P0706
Transmission Range Sensor "A" Circuit Range/Performance
TR sensor

P0707
Transmission Range Sensor "A" Circuit Low
TR sensor

P0708
Transmission Range Sensor "A" Circuit High
TR sensor

P0709
Transmission Range Sensor "A" Circuit Intermittent
TR sensor

P0710
Transmission Fluid Temperature Sensor "A" Circuit
TFT sensor

P0711
Transmission Fluid Temperature Sensor "A" Circuit Range/Performance
TFT sensor

P0712
Transmission Fluid Temperature Sensor "A" Circuit Low
TFT sensor

P0713
Transmission Fluid Temperature Sensor "A" Circuit High
TFT sensor

P0715
Turbine/Input Shaft Speed Sensor "A" Circuit
TSS sensor

P0717
Turbine/Input Shaft Speed Sensor "A" Circuit No Signal
TSS sensor

P0718
Turbine/Input Shaft Speed Sensor "A" Circuit Intermittent
TSS sensor

P0720
Output Shaft Speed Sensor Circuit
OSS sensor

P0721
Output Shaft Speed Sensor Circuit Range/Performance
OSS sensor

P0722
Output Shaft Speed Sensor Circuit No Signal
OSS sensor

P0729
Gear 6 Incorrect Ratio
Transmission

P0731
Gear 1 Incorrect Ratio
Transmission

P0732
Gear 2 Incorrect Ratio
Transmission

P0733
Gear 3 Incorrect Ratio
Transmission

P0734
Gear 4 Incorrect Ratio
Transmission

P0735
Gear 5 Incorrect Ratio
Transmission

P0740
Torque Converter Clutch Solenoid Circuit/Open
TCC solenoid

P0741
Torque Converter Clutch Solenoid Circuit Performance/Stuck Off
TCC solenoid

P0742
Torque Converter Clutch Solenoid Circuit Stuck On
TCC solenoid

P0743
Torque Converter Clutch Solenoid Circuit Electrical
TCC solenoid

P0744
Torque Converter Clutch Solenoid Circuit Intermittent
TCC solenoid

P0748
Pressure Control Solenoid "A" Electrical
LPC

P0750
Shift Solenoid "A"
SSA

P0751
Shift Solenoid "A" Performance/Stuck Off
SSA

P0752
Shift Solenoid "A" Stuck On
SSA

P0753
Shift Solenoid "A" Electrical
SSA

P0754
Shift Solenoid "A" Intermittent
SSA

P0755
Shift Solenoid "B"
SSB

P0756
Shift Solenoid "B" Performance/Stuck Off
SSB

P0757
Shift Solenoid "B" Stuck On
SSB

P0758
Shift Solenoid "B" Electrical
SSB

P0759
Shift Solenoid "B" Intermittent
SSB

P0760
Shift Solenoid "C"
SSC

P0761
Shift Solenoid "C" Performance/Stuck Off
SSC

P0762
Shift Solenoid "C" Stuck On
SSC

P0763
Shift Solenoid "C" Electrical
SSC

P0764
Shift Solenoid "C" Intermittent
SSC

P0765
Shift Solenoid "D"
SSD

P0766
Shift Solenoid "D" Performance/Stuck Off
SSD

P0767
Shift Solenoid "D" Stuck On
SSD

P0768
Shift Solenoid "D" Electrical
SSD

P0769
Shift Solenoid "D" Intermittent
SSD

P0770
Shift Solenoid "E"
SSE

P0771
Shift Solenoid "E" Performance/Stuck Off
SSE

P0772
Shift Solenoid "E" Stuck On
SSE

P0773
Shift Solenoid "E" Electrical
SSE

P0774
Shift Solenoid "E" Intermittent
SSE

P07A8
Transmission Friction Element "D" Stuck Off
Transmission

P07A9
Transmission Friction Element "D" Stuck On
Transmission

P07AA
Transmission Friction Element "E" Stuck Off
Transmission

P0815
Upshift Switch Circuit
SelectShift™ switch

P0816
Downshift Switch Circuit
SelectShift™ switch

P0826
Up and Down switch circuit
SelectShift™ switch

P0882
PCM Power Input Signal Low
Battery

P0883
PCM Power Input Signal High
Battery

P0960
Pressure Control Solenoid Control Circuit/Open
LPC

P0961
Pressure Control Solenoid Control Circuit Range/Performance
LPC

P0962
Pressure Control Solenoid Control Circuit Low
LPC

P0963
Pressure Control Solenoid Control Circuit High
LPC

P0973
Shift Solenoid "A" Control Circuit Low
SSA

P0974
Shift Solenoid "A" Control Circuit High
SSA

P0976
Shift Solenoid "B" Control Circuit Low
SSB

P0977
Shift Solenoid "B" Control Circuit High
SSB

P0979
Shift Solenoid "C" Control Circuit Low
SSC

P0980
Shift Solenoid "C" Control Circuit High
SSC

P0982
Shift Solenoid "D" Control Circuit Low
SSD

P0983
Shift Solenoid "D" Control Circuit High
SSD

P0984
Shift Solenoid "E" Range/Performance
SSE

P1001
The KOER Not Able to Complete, KOER Aborted
PCM

P1397
System Voltage Out Of Self Test Range
PCM

P1501
Vehicle Speed Sensor Out Of Self Test Range
PCM

P1502
Vehicle Speed Sensor Intermittent
PCM

P1635
Tire/Axle Out Of Acceptable Range
PCM

P1636
Inductive Signature Chip Communication Error
PCM

P163E
Transmission Control Module Programming Error
PCM

P163F
Transmission ID Block Corrupted, Not Programmed
PCM

P1700
Transmission Intermittent Failure (failed to neutral)
Transmission

P1702
Transmission Range Sensor Circuit Intermittent
TR sensor

P1705
Transmission Range Circuit Not Indicating Park/Neutral During Self Test
TR sensor

P1711
Transmission Fluid Temperature Sensor Out Of Self Test Range
TFT sensor

P1744
Torque Converter Clutch Solenoid Circuit Performance
TCC

P177F
Unable To Fully Engage Neutral
Direct or forward clutch pack

P1780
Transmission Control Switch (O/D Cancel) Circuit Out of Self-Test Range
TCS

P1783
Transmission Over Temperature Condition
Transmission

P1910
Reverse Lamp Control Circuit/Open
Reverse lamps

P1921
Transmission Range Signal
TR sensor

P2700
Transmission Friction Element "A" Apply Time Range/Performance
Transmission

P2701
Transmission Friction Element "B" Apply Time Range/Performance
Transmission

P2702
Transmission Friction Element "C" Apply Time Range/Performance
Transmission

P2703
Transmission Friction Element "D" Apply Time Range/Performance
Transmission

P2704
Transmission Friction Element "E" Apply Time Range/Performance
Transmission

P2705
Transmission Friction Element "F" Apply Time Range/Performance
Mechanical one-way clutch

P2758
Torque Converter Clutch Pressure Control Solenoid Stuck On
TCC

P2760
Torque Converter Clutch Pressure Control Solenoid Intermittent
TCC



TCCM Codes

DTC
Description

C1010:00
Continuous Vacuum Hublock (CVH) Solenoid: No Sub Type Information

C1010:11
Continuous Vacuum Hublock (CVH) Solenoid: Circuit Short to Ground

C1010:12
Continuous Vacuum Hublock (CVH) Solenoid: Circuit Short to Battery

C1010:13
Continuous Vacuum Hublock (CVH) Solenoid: Circuit Open

P0562:00
System Voltage Low: No Sub Type Information

P0563:00
System Voltage High: No Sub Type Information

P06B8:00
Internal Control Module Non-Volatile Random Access Memory (NVRAM) Error: No Sub Type Information

P1812:00
4-Wheel Drive Mode Select Circuit Failure: No Sub Type Information

P1815:00
4-Wheel Drive Mode Select Short Circuit To Ground: No Sub Type Information

P1825:00
4-Wheel Drive Clutch Relay Open Circuit: No Sub Type Information

P1826:00
4-Wheel Drive Low Clutch Relay Circuit To Battery: No Sub Type Information

P1827:00
4-Wheel Drive Low Clutch Relay Circuit To Ground: No Sub Type Information

P1839:00
Transfer Case Shift Motor Open Circuit: No Sub Type Information

P1840:00
Transfer Case Shift Motor Short Circuit To Battery: No Sub Type Information

P1841:00
Transfer Case Shift Motor Short Circuit To Ground: No Sub Type Information

P1849:00
Transfer Case Contact Plate 'A' Short Circuit To Ground: No Sub Type Information

P184A:00
Transfer Case Unable To Transition Between 4x2 and 4x4 Mode: No Sub Type Information

P184B:00
Transfer Case Unable To Transition Between 4x4 High and 4x4 Low Range: No Sub Type Information

P1853:00
Transfer Case Contact Plate 'B' Short Circuit To Ground: No Sub Type Information

P1857:00
Transfer Case Contact Plate 'C' Short Circuit To Ground: No Sub Type Information

P185A:00
Differential Lock-Up Input Switch Circuit High: No Sub Type Information

P185D:00
Differential Lock-Up Control Circuit Performance: No Sub Type Information

P1861:00
Transfer Case Contact Plate 'D' Short Circuit To Ground: No Sub Type Information

P1867:00
Transfer Case Contact Plate General Circuit Failure: No Sub Type Information

P187A:00
Transfer Case Control Module System Voltage Low - Rear Locking Differential Disabled: No Sub Type Information

P187C:00
Differential Lock-Up Control Circuit/Open

P187D:00
Differential Lock-Up Control Circuit Low

P187E:00
Differential Lock-Up Control Circuit High

P1891:00
Transfer Case Contact Plate Ground Return Open Circuit

U0100:00
Lost Communication With ECM /PCM "A": No Sub-Type Information

U0101:00
Lost Communication With TCM : No Sub Type Information

U0121:00
Lost Communication With Anti-Lock Brake System (ABS) Control Module: No Sub Type Information

U0140:00
Lost Communication With Body Control Module: No Sub Type Information

U0418:00
Invalid Data Received From Brake System Control Module: No Sub Type Information

U2300:54
Central Configuration: Missing Calibration

U2300:55
Central Configuration: Not Configured

U2300:56
Central Configuration: Invalid / Incompatible Configuration

U2300:64
Central Configuration: Signal Plausibility Failure

U3000:04
Control Module: System Internal Failure

U3000:46
Control Module: Calibration / Parameter Memory Failure

U3000:49
Control Module: Internal Electronic Failure

U300D:11
Ignition Input On/Start: Circuit Short To Ground


1 Response

Joshua Fails
Joshua Fails

February 05, 2020

Correct

Leave a comment

Comments will be approved before showing up.

Subscribe
